BLV 36-240 Battery - diely1

Podrobný popis

POS | Č. výrobku | Opis |

1 | 6.444-798.0 | Spring washer |

2 | 6.444-799.0 | Washer |

3 | 6.444-845.0 | Pusher |

4 | 6.444-801.0 | Spring plate |

5 | 6.444-846.0 | Tube outlet blade |

6 | 6.445-155.0 | Release button pipe for BLV 36-240 |

7 | 6.444-810.0 | Pressure spring |

8 | 6.445-192.0 | Set helical housing |

9 | 6.444-848.0 | Spring |

10 | 6.444-336.0 | Suction tube bottom BLV 36V |

11 | 6.444-849.0 | Screw |

13 | 6.444-808.0 | Plate |

14 | 6.444-850.0 | Lever |

15 | 6.444-851.0 | Blow nozzle tube |

16 | 6.444-809.0 | Locking ring 7,4mm |

17 | 6.444-852.0 | Fuse plug |

18 | 6.444-853.0 | Button release |

19 | 6.444-854.0 | Square nut |

20 | 6.444-792.0 | Selector switch |

21 | 6.444-794.0 | Cable with connection |

22 | 6.444-337.0 | Blow pipe bottom BLV 36V |

23 | 6.444-855.0 | Connecting element |

24 | 6.444-856.0 | Suction connection |

25 | 6.444-575.0 | Screw |

26 | 6.444-561.0 | Switch |

27 | 6.444-857.0 | Blow pipe rear |

28 | 6.444-858.0 | Trigger transmission |

29 | 6.444-859.0 | Plate change-over switch |

30 | 6.444-860.0 | Micro switch |

32 | 6.444-862.0 | Lever |

33 | 6.444-863.0 | Cable with connection |

34 | 6.444-864.0 | Spring earthing |

35 | 6.444-865.0 | Cable with connection |

36 | 6.444-658.0 | Screw |

37 | 6.444-866.0 | Screw |

38 | 6.444-867.0 | Spring |

39 | 6.444-802.0 | Screw |

40 | 6.444-896.0 | Set battery holder electronics |

41 | 6.444-381.0 | Hexagon nut M5 |

42 | 6.444-868.0 | Ferrite ring |

43 | 6.445-193.0 | Motor housing set |

44 | 6.444-870.0 | Housing shell handhold right |

49 | 6.444-784.0 | Podporné kolieska |

51 | 6.445-157.0 | Leaf bag cpl. BLV 36-240 |

55 | 6.444-872.0 | Nut |

56 | 6.444-335.0 | Suction tube above BLV 36V |

57 | 6.444-897.0 | Set motor blower wheel |

62 | 6.444-549.0 | Screw M5x0,8 Torx |

100 | 5.444-192.0 | Label Battery Power 36V BLV |

110 | 5.444-196.0 | Label 36V BLV |

120 | 5.444-195.0 | Label power adjustment 36V BLV |

130 | 5.444-194.0 | Label safety information 36V BLV |

140 | 5.444-193.0 | Label Noise 104 dB |

150 | 5.444-191.0 | Label with Kaercher logo 36V BLV |

160 | 5.444-197.0 | Tag instructions assembly 36V BLV |

170 | 5.444-198.0 | Tag instructions 36V BLV |
