HD 6/15 MXA Plus - Bubon
Kód: 7.303-108.0/64Podrobný popis
POS | Č. výrobku | Opis |
10 | 5.776-049.3 | Hose reel right |
20 | 5.776-050.3 | Hose reel Left |
30 | 5.776-051.3 | Hose reel holder right |
40 | 5.776-052.3 | Hose reel holder left |
50 | 5.646-053.3 | Spring cover |
60 | 6.269-007.0 | Power spring 25x0,55x9500 |
70 | 5.646-054.0 | Reel support left |
80 | 5.034-210.3 | Tube trolley for replacement HD-M X |
90 | 4.645-707.3 | Water connection |
100 | 4.269-019.3 | Locking pin |
110 | 5.132-020.3 | Cover |
120 | 7.303-108.0 | Skrutka 5x20 -10.9-R2R (In6Rd) |
130 | 6.303-566.0 | Skrutka 4,2x22 R2R |
150 | 4.037-013.0 | Hák |
180 | 5.064-524.0 | Rotary union support |
190 | 5.646-055.0 | Hose stop right DN6 |
200 | 5.646-056.0 | Hose stop left DN6 |
210 | 6.303-318.0 | Skrutka 3,5x12-10.9-R2R (IN6RD) |
220 | 6.110-080.0 | Hadicove vedenie TR drehbar DN6 27MPa 15 |
901 | 4.100-757.0 | Spare parts set hose guide complete |
