RLM 4 - diely1

Podrobný popis

POS | Č. výrobku | Opis |

1 | 4.445-030.0 | Cover set |

2 | 5.445-078.0 | Spring steel sheet flap |

3 | 5.445-040.0 | Cover design |

4 | 5.445-039.0 | Wheel cap |

5 | 6.445-019.0 | Castor |

6 | 6.445-026.0 | Retainer castor |

7 | 6.445-020.0 | Cutter disc |

8 | 6.445-021.0 | Cover plate USB port |

9 | 6.445-031.0 | Conversion kit battery |

10 | 4.445-080.0 | Set turning knob |

11 | 6.445-086.0 | Cartridge contact |

12 | 6.445-087.0 | Mainboard |

13 | 6.445-088.0 | Display robot |

14 | 6.445-089.0 | Cable harness battery |

15 | 6.445-090.0 | Interface cable USB |

16 | 6.445-091.0 | Main Board with cable |

17 | 6.445-092.0 | Cap D16 |

18 | 6.445-095.0 | Cable harness sensor |

19 | 6.445-096.0 | Set motor |

20 | 6.445-097.0 | Traction motor |

21 | 6.445-098.0 | Accumulator lithium ions |

22 | 6.445-100.0 | Cover plate robot |

23 | 6.445-101.0 | Chassis bottom part |

24 | 6.273-037.0 | Tesniaca šnúra penová guma 3 |

25 | 6.445-102.0 | Bearing cover |

26 | 6.445-103.0 | Seal traction motor |

27 | 6.445-104.0 | Covering cap cutter |

28 | 6.445-105.0 | Retaining bracket traction motor |

29 | 6.445-106.0 | Cover plate accumulator |

30 | 6.445-107.0 | Joint ring traction motor |

31 | 4.445-081.0 | Set height adjustment |

32 | 4.445-082.0 | Set stop pushbutton |

33 | 7.305-103.0 | Zápustná skrutka M6x16 -8.8-A2E ISO 106 |

34 | 6.445-108.0 | Device cover |

35 | 6.445-109.0 | Magnet holder |

36 | 6.445-110.0 | Screw 4X16 WN 1451 A3S |

37 | 4.445-083.0 | Set fixing cutter |

38 | 4.445-084.0 | Set drive wheel |

9500 | 2.445-026.0 | Náhradná súprava nožov |
