SC 2 Upright EasyFix EU - Main body

Podrobný popis

POS | Č. výrobku | Opis | Náhradné diely

1 | 9.754-639.0 | Housing front complete yw SC2 UP |

2 | 9.765-681.0 | Housing rear SC2 UP |

4 | 9.765-684.0 | Strain relief cable |

5 | 9.765-683.0 | Nipple tank |

6 | 5.034-505.0 | Držiak na kábel |

7 | 5.512-357.0 | Nipple steam nozzle |

8 | 4.512-130.3 | Adapter floor nozzle complete SC UP |

9 | 9.754-654.0 | Steam generator complete SC2 Up Module 220 |

10 | 9.754-611.0 | Electrical platform SC2 UP EU |

11 | 9.754-610.0 | Wire internal complete SC2 UP CN |

12 | 9.765-848.0 | Power line complete EU 5M |

20 | 6.473-093.0 | Pump CNS2-2 SC 2 Upright |

21 | 6.413-616.0 | Pressure control valve T-shape |

30 | 6.901-093.0 | Hose |

31 | 6.389-862.0 | Hadica silikón DN4 |

32 | 6.389-862.0 | Hadica silikón DN4 |

33 | 6.389-862.0 | Hadica silikón DN4 |

34 | 6.391-336.0 | Hadica |

35 | 6.391-493.0 | Hadicová objímka |

36 | 6.956-069.0 | Hose clip DW-5.5 |

37 | 5.387-036.0 | Výstražná tabuľa |

39 | 7.303-108.0 | Skrutka 5x20 -10.9-R2R (In6Rd) |

40 | 9.765-810.0 | Bearing handle complete |

41 | 6.303-199.0 | Šošovk. skrutka 4,2x 16 |

42 | 7.303-086.0 | Skrutka 5x30 -10.9-R2R (K-In6Rd) |

43 | 5.585-066.0 | Svorka |

44 | 6.362-922.0 | O-krúžok 8,73x1,78 |
